ALLNET ALL-SMC6627GREY 1U 14-slot rackmount chassis voor mediaconverter-modules, grijs

The ALLNET ALL-SMC6627GREY is a robust 19-inch 1U rack mount chassis designed to house up to 14 ALLNET media converter modules (e.g., ALL-MC1xx series). This unmanaged chassis provides a centralized, space-saving solution for deploying fiber-to-copper or other media conversion in network racks. It features an internal AC power supply with support for redundant power supplies, integrated cooling fan, and hot-swappable module slots for easy maintenance and scalability.

Advantages

Maximizes rack space efficiency by consolidating multiple media converters into a single 1U unit. Hot-swappable modules and power supplies allow for non-disruptive upgrades and replacements. The sturdy metal construction ensures durability in data center or telecom environments.

Suitable for

• Data centers requiring high-density media conversion
• Enterprise networks extending fiber connectivity
• Telecom rooms needing organized, rack-mounted conversion
• Security systems integrating fiber optic links

Key specifications

• Form Factor: 19-inch Rackmount, 1U
• Number of Slots: 14
• Compatible Modules: ALLNET Media Converter Modules (e.g., ALL-MC1xx series)
• Power Supply: Internal AC, supports redundant PSUs
• Input Voltage: AC 100-240V, 50/60 Hz
• Cooling: Integrated cooling fan
• LED Indicators: Power, Link/Activity per slot
• Material: Metal (Steel)
• Color: Grey
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 10% to 90% non-condensing
• Certifications: CE, FCC, RoHS
• Management: Unmanaged
• Hot-Swappable Support: Yes (modules and power supplies)
• Power Consumption: Max. 60W (typical, depends on modules)

Recommendations

For optimal performance, pair with ALLNET media converter modules and use redundant power supplies for mission-critical applications. Ensure proper ventilation in the rack to maintain operating temperature.
