Cisco Collaboration Power Injector 802.3at PoE+ 30W vervanging (CS-PWR-INJ-30W=)

Power over Ethernet (PoE) injectors solve the problem of delivering both data and electrical power to network devices over a single Ethernet cable, eliminating the need for separate power supplies at the device location. The Cisco Collaboration Power Injector 802.3at PoE+ 30W Spare (CS-PWR-INJ-30W=) is a spare unit designed to power Cisco IP phones, wireless access points, and other IEEE 802.3at compliant devices.

Who is it for

This injector is intended for network administrators and IT professionals who need a reliable spare PoE+ injector for Cisco collaboration endpoints. It is suitable for deployments where a PoE-enabled switch is not available or where additional power is required for devices that demand up to 30 watts.

Main features

• Complies with IEEE 802.3at (PoE+) standard, delivering up to 30W of power.
• Supports Gigabit Ethernet data rates (10/100/1000 Mbps) for high-speed connectivity.
• Compact desktop or wall-mountable design for flexible installation.
• LED indicators for power and PoE status provide at-a-glance monitoring.
• Wide input voltage range (AC 100-240V) for global compatibility.

Specifications

• Device Type: Power over Ethernet (PoE) Injector
• PoE Standard: IEEE 802.3at (PoE+)
• Power Output: 30 W
• Data Transfer Rate: 10/100/1000 Mbps
• Input Voltage: AC 100-240 V
• Input Frequency: 50/60 Hz
• Output Voltage: DC 56 V
• Ports: 1x RJ-45 (Data In), 1x RJ-45 (Data & Power Out)
• LED Indicators: Power, PoE Status
• Mounting Type: Desktop, Wall-mountable
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Operating Humidity: 5% to 90% non-condensing
• Power Plug Type: IEC 60320 C14 (AC Inlet)
• Status: Spare Part

Tips

When deploying this injector, ensure that the connected device is IEEE 802.3at compliant to avoid power delivery issues. The injector can be mounted on a wall or placed on a desktop; for wall mounting, use appropriate screws and anchors (not included). Verify that the AC power cord is compatible with your region's outlet type.
