Eaton Q18D-GE drukknop, momentcontact, 1 N/O, zwart/geel 086417

Pushbutton switch from the Eaton Q18 series, featuring a momentary actuator with a black bezel and yellow button. This non-illuminated switch provides a single normally open contact and is designed for panel mounting with a 22.5 mm diameter cutout. It offers reliable switching for control circuits up to 500 V AC, with a rated operational current of 6 A at 230 V AC-15.

Advantages

The Q18D-GE delivers robust front protection (IP66, IP67, IP69K) against dust and water ingress, making it suitable for demanding industrial environments. Its screw terminals accept conductors from 0.5 to 2.5 mm², ensuring secure and flexible wiring. With a mechanical life exceeding 5 million operations and electrical life over 1 million operations, this switch is built for long-term reliability.

Suitable for

• Control panels and operator stations in industrial machinery
• Applications requiring a momentary pushbutton with a prominent yellow actuator
• Environments where high ingress protection is essential, such as food processing or outdoor equipment

Key specifications

• Actuator type: Momentary
• Contact configuration: 1 Normally Open (N/O)
• Connection: Screw terminals
• Mounting diameter: 22.5 mm
• Rated operational current: 6 A at 230 V AC-15
• Rated operational voltage: up to 500 V AC / 250 V DC
• Front protection: IP66, IP67, IP69K
• Operating temperature: -25 to +70 °C

Recommendations

Ideal for panel builders and maintenance engineers seeking a durable, easy-to-wire pushbutton switch with high environmental protection and clear visual indication.
