ELTAKO KT4F-an korte slag drukknop 4 maakcontacten (30000077)

With a robust 10A switching capacity at 250V AC, the ELTAKO KT4F-an delivers reliable momentary control across four independent normally open contacts, making it a versatile choice for demanding electrical installations.

Overview

The ELTAKO KT4F-an is a short-stroke push-button designed for flush-mounted installation in standard 55x55mm switch programs. It features four potential-free normally open contacts, enabling simultaneous switching of multiple circuits with a single press. The device is constructed from high-quality thermoplastic in pure white, ensuring durability and a clean aesthetic that blends seamlessly with modern interiors.

What stands out

• Four independent normally open contacts for multi-circuit control
• High switching capacity: 10A at 250V AC
• Momentary action with short-stroke actuation for precise operation
• Flush-mounted design compatible with standard 55x55mm frames
• Pure white thermoplastic housing for a sleek, professional look

Technical details

• Switch type: Short-stroke push-button
• Contact configuration: 4 x NO (normally open)
• Rated voltage: 250V AC
• Rated current: 10A
• Connection: Screw terminals
• Mounting: Flush-mounted insert
• Material: Thermoplastic
• Colour: Pure white
• Protection class: IP20
• Operating temperature: -20°C to +50°C
• Mechanical life: >100,000 operations
• Electrical life: >50,000 operations
• Contact material: AgCdO
• Potential-free contacts: Yes

Our verdict

The ELTAKO KT4F-an is a dependable and efficient solution for applications requiring multiple momentary switching actions. Its high current rating and robust construction make it suitable for both residential and commercial use, while the pure white finish ensures it complements any décor.
