EVOLIGHTS 60x10W RGBW LED Wall Washer Case

The EVOLIGHTS 60x10W RGBW LED Wall Washer Case is a professional-grade outdoor lighting fixture designed for architectural and event lighting. Featuring 60 high-power 10W RGBW 4-in-1 LEDs, it delivers vibrant color mixing and smooth washes with a 25° beam angle. The IP65-rated die-cast aluminum housing ensures durability in harsh weather, while fanless convection cooling guarantees silent operation. With selectable DMX channels (4/6/8/10), multiple control modes (DMX512, Auto, Sound Active, Master/Slave), and flicker-free refresh rate >400Hz, it is ideal for stage, facade, and landscape illumination.

Advantages

High brightness with 600W power consumption, long LED lifespan of ~50,000 hours, and IP65 protection for outdoor use. The dual mounting brackets offer flexible installation, and the LED digital display simplifies configuration.

Suitable for

• Architectural wall washing
• Stage and event lighting
• Outdoor landscape illumination
• Facade and building accent lighting

Key specifications

• Light Source: 60 x 10W RGBW 4-in-1 LEDs
• Beam Angle: 25°
• DMX Channels: 4/6/8/10 selectable
• Control Modes: DMX512, Auto, Sound Active, Master/Slave
• Dimming: 0-100% linear electronic
• Strobe: 1-20 flashes/sec
• Refresh Rate: >400Hz (flicker-free)
• IP Rating: IP65
• Power Input: AC 100-240V, 50/60Hz
• Max Power Consumption: 600W
• Power Connectors: PowerCON compatible In/Out
• DMX Connectors: 3-pin XLR In/Out
• Cooling: Convection (fanless)
• Mounting: Dual mounting brackets
• Operating Temperature: -20°C to 45°C
• Certifications: CE, RoHS

Recommendations

For best results, use with a DMX controller and ensure proper power supply. Suitable for both indoor and outdoor applications where IP65 protection is required.
