GETFORT Premium Cat.6 U/UTP LSOH netwerkkabel 500m grijs

The GETFORT Premium Cat.6 U/UTP LSOH Network Cable is a high-performance twisted pair cable designed for reliable data transmission in indoor environments. With a length of 500 meters, it is ideal for structured cabling systems in offices, data centers, and commercial buildings. The cable features solid bare copper conductors (23 AWG) and a Low Smoke Zero Halogen (LSOH) jacket, ensuring safety and compliance with fire regulations.

Advantages

This cable supports up to 10 Gigabit Ethernet (10GBASE-T) at 250 MHz, making it future-proof for high-bandwidth applications. The U/UTP (unshielded twisted pair) design reduces electromagnetic interference, while the LSOH jacket minimizes toxic smoke and halogen emissions in case of fire. It meets TIA/EIA-568-C.2, ISO/IEC 11801, and EN 50173 standards.

Suitable for

• Structured cabling in offices and commercial buildings
• Data center installations
• High-speed network connections (up to 10 Gbps)
• Indoor horizontal and backbone cabling

Key specifications

• Cable Type: Twisted Pair (Cat.6)
• Shielding: U/UTP (Unshielded)
• Conductor: Solid Bare Copper, 23 AWG
• Number of Pairs: 4
• Jacket Material: LSOH (Low Smoke Zero Halogen)
• Length: 500 meters
• Max Frequency: 250 MHz
• Impedance: 100 Ohm ± 15%
• Outer Diameter: 6.2 mm
• Flame Retardancy: IEC 60332-1
• Smoke Density: IEC 61034-2
• Halogen Emission: IEC 60754-2
• Color: Grey

Recommendations

For optimal performance, use with Cat.6 compatible connectors and patch panels. Ensure proper installation practices to maintain cable specifications.
