Hirschmann Electronics RAD 015-108 RD/S universele autoradioantenne met versterker, buitenmontage, zwart

The Hirschmann Electronics RAD 015-108 RD/S is a high-performance universal car radio antenna designed for exterior roof mounting. Featuring an integrated amplifier, this antenna ensures excellent AM/FM reception for your automotive audio system. Built with durable UV-resistant materials and a sleek black finish, it combines reliability with a professional appearance.

Advantages

Integrated amplifier boosts signal strength for clear reception even in weak signal areas. Universal compatibility with standard DIN connectors makes installation straightforward. Robust construction withstands outdoor elements, ensuring long-lasting performance.

Suitable for

• Automotive radio reception in cars, trucks, and vans
• Replacement of factory or aftermarket antennas
• Vehicles requiring an amplified antenna for improved AM/FM reception

Key specifications

• Antenna Type: Universal Car Radio Antenna
• Mounting Location: Exterior (Roof Mount)
• Integrated Amplifier: Yes
• Frequency Bands: AM/FM
• Frequency Range (AM): 0.15 - 6.2 MHz
• Frequency Range (FM): 87.5 - 108 MHz
• Gain (FM): Approx. 15 dB
• Impedance: 50 Ohm
• Connector Type: DIN Plug
• Cable Length: 3 meters
• Power Supply: 12V DC (via antenna cable)
• Current Consumption: < 50 mA
• Material: UV-resistant Plastic, Metal Rod
• Color: Black
• Mounting Hole Diameter: 19 mm
• Cable Type: RG174 Coaxial
• Noise Figure: < 3 dB
• Application: Automotive Radio Reception

Recommendations

For optimal performance, ensure the antenna is mounted on a metal roof surface for proper grounding. The included 3-meter cable provides flexibility for routing to your radio unit.
