HQM USV stroomvoorziening AT-UPS2000-LCD 2000 VA line-interactieve USV

The HQM AT-UPS2000-LCD is a line-interactive uninterruptible power supply (UPS) designed to protect critical equipment from power outages, surges, and fluctuations. With a capacity of 2000 VA / 1200 W, it provides reliable battery backup and surge protection for servers, networking devices, and home electronics. The LCD panel displays real-time status, and the unit features USB, RJ45, and RJ11 communication ports for comprehensive protection.

Advantages

Line-interactive topology ensures efficient voltage regulation and fast transfer time (2-6 ms typical). Maintenance-free sealed lead-acid batteries provide long service life. The combination of Schuko and IEC C13 outlets offers flexibility for various devices. Compact tower design saves space.

Suitable for

• Home offices and small businesses
• Network equipment (routers, switches, modems)
• Desktop computers and workstations
• Security systems and surveillance equipment

Key specifications

• UPS Topology: Line-Interactive
• Apparent Power Capacity: 2000 VA
• Active Power Capacity: 1200 W
• Input Voltage Range: 162 - 290 VAC
• Input Frequency: 50/60 Hz (Auto-sensing)
• Output Voltage (Battery Mode): 230 VAC ±10%
• Output Frequency (Battery Mode): 50/60 Hz ±1 Hz
• Output Waveform (Battery Mode): Simulated Sine Wave
• Transfer Time: 2-6 ms (typical), 10 ms (max)
• Battery Type: Sealed Lead-Acid (Maintenance-Free)
• Battery Configuration: 2 x 12V/9Ah
• Battery Recharge Time: 4-6 hours to 90% capacity
• Output Sockets: 2x Schuko, 2x IEC C13
• Communication Ports: USB, RJ45 (In/Out), RJ11 (In/Out)
• Display Type: LCD Panel
• Protection Features: Overload, Short Circuit, Overcharge, Over-discharge
• Noise Level: < 40 dB

Recommendations

For optimal performance, connect only critical devices and ensure the UPS is placed in a well-ventilated area. Regularly test the battery and replace every 3-5 years. This UPS is ideal for protecting sensitive electronics from power disturbances.
