HT Instruments 4324-2 veiligheids-meetsnoerset 1,5 m rood, zwart (1003075)

Safety test lead set with two 1.5 m leads, one red and one black, designed for reliable measurements with multimeters, clamp meters, and electrical testers. Each lead is terminated with straight 4 mm safety plugs on both ends, ensuring secure and stable connections. Rated for CAT III 1000 V and CAT IV 600 V, with a current capacity of 16 A. Double insulated PVC construction with copper conductors provides durability and safety. Compliant with IEC/EN 61010-031.

Advantages

Double insulation and PVC jacket offer excellent protection against electrical hazards. The 4 mm shrouded banana plugs fit securely into standard test instrument inputs, preventing accidental contact. The 1.5 m length provides flexibility in various measurement scenarios, while the red and black color coding allows easy polarity identification.

Suitable for

• Multimeters
• Clamp meters
• Electrical testers
• General electrical testing in CAT III and CAT IV environments

Key specifications

• Lead length: 1.5 m
• Color: Red, Black
• Number of leads: 2
• Connector type: 4 mm safety plug (straight), shrouded banana plug
• Safety rating: CAT III 1000 V, CAT IV 600 V
• Rated current: 16 A
• Insulation: Double insulated, PVC
• Conductor material: Copper
• Compliance: IEC/EN 61010-031
• Operating temperature: -15°C to +70°C
• Resistance per lead: < 0.05 Ω

Recommendations

Ideal for professionals who require reliable and safe test leads for high-voltage measurements. The set includes one red and one black lead, providing a complete solution for most multimeter applications.
