LEAN CARS 24V 200W 12000 RPM motor links - A011

The LEAN CARS 24V 200W 12000 RPM Engine Left - A011 is a high-performance brushed DC motor designed for demanding applications such as electric scooters, robotics, and general purpose machinery. With a robust metal housing and air-cooled design, this motor delivers reliable power and durability.

Advantages

This motor offers a powerful 200W output at 24V, reaching a no-load speed of 12000 RPM. Its left-hand rotation (counter-clockwise from shaft end) makes it ideal for specific drive configurations. The flange mount with four M6 threaded holes ensures secure installation, while the 8mm shaft provides compatibility with a wide range of couplings and pulleys.

Suitable for

• Electric scooters and go-karts
• Robotics and automation projects
• General purpose motor applications

Key specifications

• Motor Type: Brushed DC Motor
• Operating Voltage: 24V DC
• Rated Power Output: 200W
• No-load Rotational Speed: 12000 RPM
• Rated Current: Approx. 8.33A
• Direction of Rotation: Left (Counter-Clockwise from shaft end)
• Shaft Diameter: 8 mm
• Shaft Length: Approx. 35 mm
• Body Diameter: 68 mm
• Total Length (incl. shaft): Approx. 135 mm
• Mounting Type: Flange Mount
• Number of Mounting Holes: 4
• Mounting Hole Thread: M6
• Mounting Hole Spacing (Diagonal): 70 mm
• Rated Torque: Approx. 0.16 Nm
• Housing Material: Metal
• Cooling Method: Air-cooled

Recommendations

For optimal performance, ensure proper ventilation and use a suitable motor controller rated for 24V and 200W. Always follow safety guidelines when installing and operating high-power motors.
