Rittal TS 8611.340 schakelkastframe, wit, compatibel met TS/TS IT/SE/PC/IW

Rittal TS 8611.340 is a white cabinet enclosure frame designed for use with Rittal TS series and compatible TS IT, SE, PC and IW systems. It functions as a structural frame for electrical and IT enclosures, providing a stable mounting surface for panels, components, and accessories. The frame is supplied as a single unit and is intended to integrate into existing rack and cabinet assemblies to form a protective housing or support structure for wiring and equipment.

Advantages

The enclosure frame offers a standardized mounting interface compatible with multiple Rittal system variants, enabling straightforward assembly and component alignment. Its white finish provides a neutral appearance suitable for a range of environments, while the robust construction ensures reliable mechanical support for mounted equipment. Lightweight packaging simplifies handling during installation and transport.

Suitable for

Key specifications

How to use

Mount the frame into a compatible cabinet or rack following the mechanical alignment and fastening points of the TS series system. Position panels, mounting plates, or components onto the frame using appropriate screws and accessories designed for the Rittal system. Ensure that the frame is secured to the cabinet structure and that clearances for cabling and ventilation are maintained. Use the frame as a base for installing terminal blocks, DIN-rail mounted devices, or IT equipment according to the enclosure layout.

Recommendations

Confirm compatibility with your specific TS, TS IT, SE, PC or IW cabinet model before installation. Use corrosion-resistant fasteners in corrosive environments and follow applicable electrical and safety standards when mounting live equipment. For transportation and handling, avoid heavy impacts and store the frame in a dry location prior to installation.
