RUKO MGR-DIN357-M8x1,25mm ringbout, verzinkt staal, M8 draad, 40 mm lengte

With an inner eye diameter of 20 mm and a robust zinc-plated steel construction, this M8 eye bolt provides a reliable anchoring point for general fastening and securing tasks. The DIN 357 standard ensures consistent dimensions and thread compatibility.

Overview

The RUKO GMBH MGR-DIN357-M8x1.25mm eye bolt is a metric-threaded fastener with a closed eye head, designed for creating secure attachment points in wood, metal, or plastic. The zinc plating offers moderate corrosion resistance, making it suitable for indoor and some outdoor applications where exposure to moisture is limited.

What stands out

• Conforms to DIN 357 for reliable interchangeability
• M8 x 1.25 mm metric thread for standard nut compatibility
• Zinc-plated steel balances strength and corrosion protection
• 20 mm inner eye diameter accommodates hooks, ropes, or cables

Technical details

• Standard: DIN 357
• Fastener type: Eye bolt
• Thread type: Metric
• Thread size: M8
• Thread pitch: 1.25 mm
• Material: Steel
• Finish: Zinc-plated
• Overall length (L): 40 mm
• Thread length (b): 22 mm
• Inner eye diameter (d2): 20 mm
• Outer eye diameter (d3): 36 mm
• Eye thickness (k): 8 mm
• Nominal diameter (d): 8 mm
• Head type: Eye

Our verdict

A dependable eye bolt for non-lifting anchoring and fastening jobs, offering a good balance of strength, corrosion resistance, and standard compliance.
