Siemens 6ES7307-1KA02-0AA0 digitaal/analoog I/O-module analoog

The Siemens 6ES7307-1KA02-0AA0 is an analog/digital I/O module intended for use in automation and system power applications. It provides a compact interface for signal exchange between field devices and a control system, with multicolour status indicators for quick visual assessment. The unit's dimensions are 170 mm width and 90 mm depth, and it weighs approximately 800 g, making it suitable for installation in cabinets and control racks where space and weight are considerations.

Advantages

This I/O module combines analog and digital signal handling in a single device, reducing the need for multiple separate modules. Multicolour indicators give clear visual feedback on module and channel status, helping technicians identify operating states and faults quickly. Its compact footprint and moderate weight simplify mounting and integration into existing control panels. Designed by a manufacturer with established compatibility standards, the module supports reliable data processing and predictable behavior within industrial automation architectures.

Suitable for

Key specifications

How to use

Install the module on a compatible mounting rail or into the designated slot of the automation rack following the control system manufacturer's mechanical and electrical installation instructions. Connect field wiring for analog sensors and digital signals to the appropriate terminals, observing polarity and signal type. Use the multicolour LEDs to verify power status and channel activity during commissioning. Configure the host controller or PLC to recognize the module's channels and assign signal types, ranges, and diagnostic parameters through the automation system software.

Recommendations

Ensure that supply voltages and signal ranges match the requirements of connected devices and the host system. Observe electrostatic discharge (ESD) precautions during handling and perform commissioning tests with known reference signals. Regularly inspect LED indicators during maintenance to detect degraded channels or connection issues early.
