UNI-T UDP6721 laboratoriumvoeding, 0-72 V DC, 0-1 A, 72 W, enkelkanaals, programmeerbaar

The UNI-T UDP6721 stands out as a precision single-channel DC laboratory power supply, delivering a wide 0–72 V output range with 1 mV voltage and 0.1 mA current resolution. Unlike many bench supplies in its class, it combines a 2.8-inch TFT LCD display, USB/RS232/LAN connectivity, and 10 memory presets — making it a flexible tool for electronics development, testing, and repair.

Highlights

• Single output channel: 0–72 V DC, 0–1 A, up to 72 W
• High resolution: 1 mV / 0.1 mA setting and readback
• Low ripple & noise: ≤1 mVrms (voltage), ≤1 mArms (current)
• 2.8-inch TFT LCD for clear, real-time monitoring
• Communication interfaces: USB Device, RS232, LAN
• Protection: OVP, OCP, OTP
• 10 memory presets for quick recall of common settings
• Excellent regulation: load/line ≤0.01% + 2 mV / 2 mA

In daily use

This power supply is ideal for benchtop tasks requiring stable and precise DC output — from powering prototypes to testing components. The fast transient response (<50 µs) ensures clean power delivery even under dynamic loads. The intuitive interface and preset storage streamline repetitive work, while remote control via USB, RS232, or LAN enables automated testing and data logging.

Full specifications

• Output channels: 1
• Output voltage range: 0–72 V DC
• Output current range: 0–1 A DC
• Maximum output power: 72 W
• Voltage setting resolution: 1 mV
• Current setting resolution: 0.1 mA
• Voltage readback resolution: 1 mV
• Current readback resolution: 0.1 mA
• Load regulation (voltage): ≤0.01% + 2 mV
• Load regulation (current): ≤0.01% + 2 mA
• Line regulation (voltage): ≤0.01% + 2 mV
• Line regulation (current): ≤0.01% + 2 mA
• Ripple & noise (voltage): ≤1 mVrms
• Ripple & noise (current): ≤1 mArms
• Transient response time: <50 µs
• Display: 2.8-inch TFT LCD
• Communication: USB Device, RS232, LAN
• Protection: OVP, OCP, OTP
• Memory presets: 10 groups
• Input voltage: 100V/120V/220V/230V AC, 50/60Hz

Final note

The UNI-T UDP6721 combines precision, connectivity, and ease of use — a dependable choice for professionals and hobbyists who demand accurate and programmable DC power.
