Voeding MEAN WELL 192W 12V IP67 — LED-driver, model 51405024

Mean Well 192W 12V IP67 power supply is a constant-voltage LED driver designed to deliver up to 192 watts of stable 12 V DC output with full environmental protection. Constructed for indoor and outdoor installations, the unit features an IP67-rated housing that protects electronics from dust and temporary immersion in water. The driver provides a reliable supply for LED strips, modules and low-voltage fixtures used in signage, architectural lighting and other 12V LED applications.

Advantages

The power supply offers a high output power density and stable voltage regulation to minimize flicker and ensure uniform light performance. Its IP67 enclosure and robust build allow safe operation in damp, dusty or exposed environments. Built-in protection functions contribute to long-term reliability by safeguarding against overload, short-circuit and over-temperature conditions. Compact physical dimensions and standardized DC output make it simple to integrate into existing LED systems.

Suitable for

Key specifications

How to use

Install the power supply in a location consistent with its IP67 rating, ensuring cable entries and connections are sealed and strain-relieved. Connect the 12 V DC output to the LED load, observing correct polarity. Confirm that the total connected LED wattage does not exceed the maximum 192 W rating and allow adequate ventilation around the unit for heat dissipation. Follow local electrical codes when making mains connections and, if required, engage a qualified electrician to perform installation and grounding.

Recommendations

Use compatible LED products rated for 12 V DC and size the total load to 80–90% of the maximum output for improved longevity. Avoid continuous operation at full rated power in high ambient temperatures and protect input wiring from prolonged exposure to direct sunlight or standing water.
