Xerox Crease and Two Sided Trimmer (PR Finisher) - productie-finishingmodule

Enhance your production workflow with the Xerox Crease and Two Sided Trimmer (PR Finisher), an inline finishing module that integrates precision creasing and dual-side trimming into a single, automated unit. This module enables professional-quality booklets, brochures, and business cards directly from your production press, eliminating the need for offline finishing and reducing material handling.

Advantages

By combining creasing and trimming processes, this module saves time and reduces material handling. It delivers accurate, repeatable trims on both lead/trail and side edges with a tolerance of ±0.5 mm. The creasing function, which applies up to five creases per sheet, prevents cracking on heavyweight stocks, ensuring crisp, fold-ready output.

Suitable for

• High-volume document production
• Booklets and brochures
• Business cards
• Marketing collateral requiring precise finishing

Key specifications

• Trimming: Two-sided (lead/trail and side edge)
• Max trim amount: 25 mm (lead/trail), 12.5 mm per side
• Creasing: Up to 5 creases per sheet
• Media size: 182 x 182 mm to 330 x 488 mm
• Media weight: 60 to 400 gsm
• Automated job setup and registration
• Inline integration with Xerox production presses
• Power: 100-240 VAC, 50/60 Hz
• Trim accuracy: ±0.5 mm

Recommendations

For optimal performance, use with Xerox recommended media and maintain the module per the manufacturer's guidelines. This unit is designed for continuous high-volume operation.
