ABB STOTZ-KONTAKT 3-polige lastscheider 400V 100A E203/100R 2CDE283001R0100

When a main switch must reliably isolate a three-phase circuit up to 100 A, the ABB E203/100R provides a compact DIN-rail solution. This 3-pole load disconnector is built for manual switching under load and offers clear ON/OFF indication for safe maintenance.

Who is it for

Panel builders and electricians who need a robust main switch for distribution boards, motor feeders, or industrial control panels. Its 3-module width saves space without compromising performance.

Main features

• Rated current 100 A, operational voltage 400 V AC
• 3-pole switching, suitable for three-phase systems
• Screw terminals accept rigid conductors up to 50 mm²
• DIN-rail mounting, 3 modules wide (52.5 mm)
• Mechanical endurance 20,000 cycles
• Operating temperature -25 °C to +55 °C

Specifications

• Number of poles: 3
• Rated operational voltage (Ue): 400 V AC
• Rated insulation voltage (Ui): 440 V
• Rated impulse withstand voltage (Uimp): 4 kV
• Rated short-circuit making capacity (Icm): 1.5 kA at 230 V
• Rated short-circuit withstand current (Icw): 1 kA for 1 s
• Electrical endurance: 10,000 cycles
• Terminal capacity (rigid): 1.5 - 50 mm²
• Terminal capacity (flexible): 1.5 - 35 mm²
• Degree of protection: IP20 (terminals)
• Standards: IEC/EN 60947-3

Tips

Use as a main switch in distribution boards or as a disconnector for individual loads. The screw terminals provide a secure connection for large conductors; ensure proper torque during installation.
