ABB STOTZ-KONTAKT isolatiebehuizing IB132-G, 2-modulig, opbouw, IP30, wit (1SAM201911R1010)

Rated insulation voltage of 500 V and double-insulated Class II construction make the ABB IB132-G a robust housing for modular DIN rail devices, even in demanding low-voltage installations. This 2-module insulating enclosure keeps miniature circuit breakers and residual current devices protected in a compact, surface-mounted footprint.

Overview

The IB132-G is a one-row insulating enclosure from ABB STOTZ-KONTAKT, engineered for safe and tidy installation of two standard modular devices. Its thermoplastic body offers reliable electrical isolation and mechanical protection, while the clean white finish integrates discreetly into residential and commercial distribution boards.

What stands out

• Double-insulated (Class II) housing – no earthing required
• IP30 protection against solid objects over 2.5 mm
• Withstands glow wire test at 650 °C for enhanced fire safety
• Wide operating temperature range from -25 °C to +60 °C
• Complies with IEC/EN 60670-24 and IEC/EN 62208

Technical details

• Product type: Insulating enclosure
• Number of modules: 2
• Number of rows: 1
• Material: Thermoplastic
• Colour: White
• Mounting type: Surface mounted
• Rated insulation voltage (Ui): 500 V
• Rated operational voltage (Ue): 400 V AC
• Protection degree: IP30
• Insulation class: Class II
• Glow wire test: 650 °C
• Ambient operating temperature: -25 to +60 °C
• Standards: IEC/EN 60670-24, IEC/EN 62208

Our verdict

A dependable, no-fuss enclosure for two DIN rail modules. Its double insulation and high glow wire rating deliver extra safety margins.
