Alcatel-Lucent Enterprise Primary Rate Interface Board EDSS1-S2M 3EH77037AA

The Alcatel-Lucent Enterprise Primary Rate Interface Board (3EH77037AA) is a high-performance PRI module designed for seamless integration with Alcatel-Lucent OmniPCX Enterprise and OmniPCX Office communication systems. This board provides a reliable E1 (G.703) interface with EDSS1 signaling, enabling efficient PSTN trunk line connectivity for voice and data communication.

Advantages

This PRI board ensures robust and scalable connectivity for business telephony systems. It supports 30 B-channels and 1 D-channel, delivering a data transmission rate of 2.048 Mbps. With support for multiple clocking modes (internal, external, loop-timed) and HDB3 line coding, it offers flexibility and reliability in various network environments.

Suitable for

• Alcatel-Lucent OmniPCX Enterprise and OmniPCX Office systems
• Businesses requiring primary rate ISDN connectivity for PSTN trunk lines
• Voice and data communication applications needing high-capacity digital trunks

Key specifications

• Product Type: Primary Rate Interface (PRI) Board
• Interface Standard: E1 (G.703)
• Signaling Protocol: EDSS1 (Euro-ISDN)
• Channel Configuration: 30 B-channels + 1 D-channel
• Data Transmission Rate: 2.048 Mbps
• Connection Type: S2M (Primary Rate Interface)
• Number of Ports: 1 x E1 Port
• Technology: ISDN
• Mounting: Internal Module/Card
• Standard Compliance: ITU-T G.703, G.704, G.706, G.732
• Line Coding: HDB3
• Frame Structure: G.704 (PCM30)
• Manufacturer Part Number: 3EH77037AA
• Brand Compatibility: Alcatel-Lucent Enterprise

Recommendations

This PRI board is an ideal solution for expanding or upgrading your Alcatel-Lucent telephony infrastructure. Ensure compatibility with your specific OmniPCX model before purchase. For optimal performance, use with compatible Alcatel-Lucent systems and follow installation guidelines.
