Alcatel Lucent OmniSwitch OS2260-24 - Managed Layer 2-switch - 24 x Gigabit Ethernet + 4 x SFP Uplink - Rack-mountable 1U - ventilatorloos

The Alcatel Lucent OmniSwitch OS2260-24 is a high-performance managed Layer 2 switch designed for enterprise and SMB networks. With 24 Gigabit Ethernet ports and 4 SFP uplinks, it delivers reliable, high-speed connectivity for demanding environments. Its fanless design ensures silent operation, making it ideal for open offices and noise-sensitive areas.

Advantages

Energy-efficient with IEEE 802.3az EEE support, the OS2260-24 reduces power consumption without compromising performance. Advanced security features like port security, DHCP snooping, and 802.1X protect your network from unauthorized access. The switch supports VLANs, QoS, and link aggregation for optimized traffic management.

Suitable for

• Enterprise access layer deployments
• SMB networks requiring robust switching
• Noise-sensitive environments (fanless)
• Rack-mountable installations

Key specifications

• 24 x 10/100/1000Base-T RJ-45 ports
• 4 x Gigabit SFP uplink ports
• Switching capacity: 56 Gbps
• Forwarding rate: 41.6 Mpps
• MAC address table: 8K entries
• Jumbo frame support up to 9KB
• Management: CLI, Web GUI, SNMP, RMON
• VLAN support: IEEE 802.1Q, Voice VLAN
• QoS: 802.1p, DSCP
• Security: Port Security, DHCP Snooping, IP Source Guard, DoS Protection, 802.1X
• Spanning Tree: STP, RSTP, MSTP
• Link Aggregation: LACP
• IPv6 support
• RAM: 256 MB, Flash: 32 MB
• Form factor: 1U rack-mountable
• Fanless design
• Energy Efficient Ethernet (EEE)

Recommendations

For optimal performance, pair with Alcatel Lucent SFP transceivers. Ensure proper ventilation in rack environments despite fanless operation.
