ALLNET ALL-BRICK-0052 10 Ohm 10W draadweerstand, behuizingsmontage, schroefaansluitingen

The ALLNET ALL-BRICK-0052 is a robust 10 Ohm, 10W wirewound resistor designed for chassis mounting with screw terminals. Ideal for dummy loads, power dissipation, circuit testing, and educational projects, this resistor offers reliable performance in a compact aluminum housing.

Advantages

High power handling in a small form factor, excellent heat dissipation via aluminum housing, and easy installation with screw terminals. Suitable for continuous operation in demanding environments.

Suitable for

• Dummy load applications
• Power dissipation in circuits
• Circuit testing and prototyping
• Educational and hobbyist projects

Key specifications

• Resistance: 10 Ohm
• Power Rating: 10W
• Tolerance: ±5%
• Type: Wirewound
• Mounting: Chassis Mount
• Connection: Screw Terminals
• Operating Temperature: -55°C to +155°C
• Temperature Coefficient: ±300 ppm/°C
• Dielectric Strength: 1000V AC
• Core Material: Ceramic
• Housing Material: Aluminum
• Number of Terminals: 2
• Insulation Resistance: >100 MΩ at 500V DC
• Overload Capacity: 1.5x rated power for 5 seconds
• Cooling: Air Cooled
• RoHS Compliant

Recommendations

For optimal performance, ensure proper mounting on a heat sink or chassis to maximize heat dissipation. This resistor is not suitable for high-frequency applications.
