ALLNET MSR analoge schoksensor ALL3043

The ALLNET MSR Analog Shock Sensor ALL3043 is a high-precision MEMS accelerometer-based sensor designed for measuring shock and vibration in a wide range of industrial and research applications. As an analog sensor, it provides a continuous voltage output proportional to the applied acceleration, making it ideal for integration with MSR data loggers and other measurement systems.

Advantages

This sensor offers configurable measurement ranges (±15g, ±100g, ±200g) to suit different shock levels, ensuring accurate data capture. Its robust plastic housing and IP60 protection class make it suitable for demanding environments. The 1-meter cable and proprietary 3-pin connector ensure easy and reliable connection to compatible MSR data loggers.

Suitable for

• Shock and impact monitoring in transportation and logistics
• Vibration analysis in industrial machinery
• Structural health monitoring
• Research and development testing

Key specifications

• Sensor Type: Analog Shock Sensor (MEMS Accelerometer)
• Measurement Axes: 1-axis (Single-axis)
• Measurement Range: ±15g, ±100g, ±200g (configurable)
• Output Signal: Analog, 0 to 3.0 V DC
• Resolution: 12-bit (when used with MSR data loggers)
• Accuracy: ±2.5% of full scale
• Frequency Range: 0 Hz to 1 kHz
• Operating Temperature: -20°C to +65°C
• Storage Temperature: -20°C to +75°C
• Connection Interface: MSR 3-pin proprietary connector
• Cable Length: 1.0 meter
• Power Supply: 3.0 V DC (supplied by data logger)
• Housing Material: Robust Plastic
• Protection Class: IP60
• Response Time: < 1 ms
• Mounting Type: Integrated mounting holes

Recommendations

For optimal performance, pair this sensor with an MSR145, MSR165, MSR175, or MSR255 data logger. Ensure the sensor is securely mounted and the cable is properly connected to avoid signal interference.
