APC Easy Rack PDU Basic - stroomverdeleenheid (rack-montage)

The APC Easy Rack PDU Basic is a reliable and cost-effective power distribution solution designed for data centers and network cabinets. This 1U rack-mountable unit provides 12 IEC C13 outlets, enabling efficient power distribution to connected equipment. With a 3.05-meter input cord and a maximum current of 16A at 230V, it ensures stable power delivery for servers, switches, and other IT devices.

Advantages

Easy to install and operate, the APC Easy Rack PDU Basic offers a straightforward, no-frills approach to power distribution. Its basic design eliminates unnecessary complexity, making it ideal for environments where simple power distribution is required without monitoring or switching capabilities. The unit is built to high standards, with certifications including CE, EN 55022 Class A, EN 55024, IEC 60950-1, and VDE, ensuring safety and reliability.

Suitable for

• Data centers requiring basic power distribution
• Network cabinets and server racks
• IT environments needing reliable 230V power distribution
• Applications where metering or switching is not required

Key specifications

• PDU Type: Basic Rack PDU
• Form Factor: 1U Rack-mount
• Input Voltage: 230V
• Input Frequency: 50/60 Hz
• Input Connector: IEC 60320 C20
• Input Current (Max): 16A
• Output Voltage: 230V
• Output Connectors: 12 x IEC 60320 C13
• Output Current (Max per phase): 16A
• Overload Protection: No
• Metering: No
• Management: No
• Cord Length: 3.05 m
• Mounting Position: Horizontal
• Color: Black
• Certifications: CE, EN 55022 Class A, EN 55024, IEC 60950-1, VDE
• Operating Temperature: 0 - 45 °C
• Operating Relative Humidity: 0 - 95 %

Recommendations

For optimal performance, ensure that the total connected load does not exceed 16A. This PDU is best suited for environments where basic power distribution is sufficient. For advanced monitoring or switching needs, consider APC's metered or switched PDU models.
