ASI COLLECTION RVS kanaalklem voor Fischer FHS montagerails

Channel clamp made of stainless steel A4 (AISI 316) for secure fixing of pipes, conduits, cable trays, and other installations to Fischer FHS mounting channels. The clamp slides into the channel and is tightened with a screw, offering adjustable positioning along the channel length. Its high corrosion resistance makes it suitable for outdoor, industrial, and aggressive environments.

Advantages

Dual thread connection (M8/M10) provides flexibility for different screw sizes. The stainless steel construction ensures long-lasting performance even in harsh conditions. Adjustable along the channel for precise positioning.

Suitable for

• Fixing pipes, conduits, and cable trays to Fischer FHS channels
• Outdoor and industrial applications requiring high corrosion resistance
• Installations in aggressive environments such as chemical plants or coastal areas

Key specifications

• Material: Stainless Steel A4 (AISI 316)
• Thread connection: M8 / M10 (dual thread)
• Compatibility: Fischer FHS mounting channels
• Max recommended tensile load: 1.5 kN
• Temperature resistance: -50°C to +150°C
• Standard compliance: DIN EN ISO 3506-1

Recommendations

For secure and corrosion-resistant fastening in demanding environments, pair this clamp with Fischer FHS channels and appropriate stainless steel screws.
