ASUS Q670EI-IM-A LGA 1700 Mini-ITX moederbord DDR5 3xDP+HDMI vPro 24/7

The ASUS Q670EI-IM-A is a high-performance Mini-ITX motherboard designed for industrial, commercial, and embedded applications. Built on the Intel Q670 chipset with an LGA 1700 socket, it supports 12th/13th Gen Intel Core processors and delivers robust connectivity, reliability, and 24/7 operation capability.

Advantages

This motherboard offers a compact form factor without compromising on features. With Intel vPro support, it provides advanced manageability and security for business environments. The dual 2.5 Gigabit Ethernet ports ensure fast and stable network connections, while the multiple display outputs (3x DisplayPort + 1x HDMI) enable versatile multi-monitor setups. Designed for continuous operation, it is ideal for digital signage, kiosks, and industrial automation.

Suitable for

• Industrial PCs and embedded systems
• Commercial workstations and thin clients
• Digital signage and kiosk applications
• 24/7 operation environments

Key specifications

• CPU Socket: LGA 1700
• Chipset: Intel Q670
• Form Factor: Mini-ITX
• Memory: 2x DDR5 DIMM slots, max 64 GB
• Video Outputs: 3x DisplayPort, 1x HDMI
• Expansion: 1x PCIe 4.0 x16
• Storage: 2x M.2 PCIe 4.0 x4, 4x SATA 6Gb/s
• LAN: 2x Intel 2.5 Gigabit Ethernet
• Audio: Realtek ALC897
• USB Rear: 2x USB 3.2 Gen 2, 2x USB 3.2 Gen 1, 2x USB 2.0
• Power: 24-pin ATX + 8-pin EPS
• Intel vPro support
• 24/7 continuous operation

Recommendations

For optimal performance, pair this motherboard with an Intel Core i5 or i7 12th/13th Gen processor and DDR5 memory. Ensure adequate cooling for 24/7 operation. The dual Ethernet ports allow for network redundancy or separate LAN segments.
