BADKAMER UNI 150 WANDSET

The BATHROOM UNI 150 WALLS SET is a high-quality axial fan designed for efficient ventilation in bathrooms, kitchens, utility rooms, and other residential or commercial spaces. With a duct diameter of 150 mm and an airflow capacity of 250 m³/h, it ensures effective air extraction while maintaining low noise levels at just 38 dB(A). The fan features a telescopic duct with adjustable length from 250 to 480 mm, making it suitable for various wall thicknesses. Its IPX4 splash-proof rating guarantees safe operation in humid environments.

Advantages

This wall-mounted fan offers reliable performance with a power consumption of only 20 W, making it energy-efficient. The included components – axial fan, internal decorative grille, external gravity grille/hood, and telescopic duct – provide a complete solution for through-the-wall installation. The white ABS plastic construction ensures durability and a clean aesthetic that blends with any decor.

Suitable for

• Bathrooms and shower rooms
• Kitchens
• Utility rooms
• Residential and commercial spaces requiring ventilation

Key specifications

• Duct Diameter: 150 mm (6 inches)
• Airflow Capacity: 250 m³/h
• Noise Level: 38 dB(A)
• Power Consumption: 20 W
• Voltage: 220-240 V, 50 Hz
• IP Rating: IPX4 (Splash-proof)
• Material: High-quality ABS Plastic
• Installation Type: Through-the-wall mounting
• Duct Type: Telescopic, adjustable length 250-480 mm
• Color: White
• Control Method: External switch (not included)
• Operating Temperature: Up to +40°C
• Motor Type: Single-phase asynchronous
• Bearing Type: Sleeve bearings

Recommendations

For optimal performance, ensure the duct is properly sealed and the external grille is unobstructed. Use an appropriate external switch for control. This fan is ideal for rooms up to 10 m² with standard ceiling heights.
