BlueOptics CBL-NTWK-0942-MQ28E10M-BL InfiniBand-kabel 1 m QSFP28 oranje

The BlueOptics CBL-NTWK-0942-MQ28E10M-BL is a high-performance InfiniBand Direct Attach Copper (DAC) cable designed for data centers and high-performance computing (HPC) environments. With a length of 1 meter and QSFP28 connectors on both ends, this passive cable supports EDR (Enhanced Data Rate) at 100 Gbps, ensuring reliable, low-latency connectivity for demanding applications.

Advantages

This cable offers a cost-effective and energy-efficient solution for short-range InfiniBand connections. Its passive design consumes minimal power (typically less than 0.5W per end) and provides excellent signal integrity. The orange jacket makes it easy to identify in dense cable runs, and the PVC material ensures durability and flexibility.

Suitable for

• Data center interconnects
• High-performance computing clusters
• Enterprise networking with QSFP28 ports
• InfiniBand EDR switches and HBAs

Key specifications

• Cable Type: InfiniBand Direct Attach Copper (DAC)
• Connector Type: QSFP28 Male to QSFP28 Male
• Cable Length: 1 meter (3.3 feet)
• Data Transfer Rate: 100 Gbps
• InfiniBand Standard: EDR (Enhanced Data Rate)
• Cable Material: Copper
• AWG: 30 AWG
• Color: Orange
• Passive/Active: Passive
• Jacket Material: PVC
• Hot-Swappable: Yes
• RoHS Compliant: Yes
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C

Recommendations

For optimal performance, ensure that both connected devices support InfiniBand EDR and QSFP28 interfaces. This cable is ideal for rack-to-rack or server-to-switch connections within the same rack. For longer distances, consider active optical cables or fiber optic solutions.
