BlueOptics Infortrend 9370CSFP200G-0010 QSFP56-transceiver, 200GBASE-SR4, multimode vezel, 850nm, 100 meter

The BlueOptics Infortrend 9370CSFP200G-0010 QSFP56 Transceiver is a high-performance optical module designed for 200 Gigabit Ethernet applications. It is fully compatible with Infortrend 9370CSFP200G-0010 systems and supports the 200GBASE-SR4 standard over multimode fiber. With a wavelength of 850nm and a maximum reach of 100 meters on OM4 fiber, this transceiver is ideal for high-speed data center interconnects and enterprise networking.

Advantages

This transceiver offers reliable, high-bandwidth connectivity with low power consumption (<4.5W typical). It supports Digital Diagnostic Monitoring (DDM/DOM) for real-time performance monitoring. The hot-pluggable QSFP56 form factor ensures easy installation and maintenance. Compliance with IEEE 802.3cd and QSFP56 MSA guarantees interoperability.

Suitable for

• High-speed data center interconnects
• Enterprise networking
• Infortrend storage systems requiring 200G connectivity
• Short-reach multimode fiber links up to 100m

Key specifications

• Form Factor: QSFP56
• Data Rate: 200 Gbps
• Standard: 200GBASE-SR4
• Wavelength: 850 nm
• Fiber Type: Multimode (MMF)
• Max Distance: 100m (OM4), 70m (OM3)
• Connector: MPO/MTP-12 (APC)
• Transmitter: VCSEL
• Receiver: PIN Photo Detector
• DDM/DOM: Yes
• Hot-Pluggable: Yes
• Power Consumption: <4.5W
• Operating Temperature: 0°C to 70°C
• Compliance: IEEE 802.3cd, QSFP56 MSA, RoHS

Recommendations

For optimal performance, use with OM4 multimode fiber and ensure proper MPO connector cleaning. This transceiver is a direct replacement for Infortrend 9370CSFP200G-0010 original modules.
