BOSCH PRO GDI59-500 trilnaald (zwart/blauw, 59 mm trilnaaldkop)

The BOSCH PRO GDI59-500 Concrete Vibrator is a high-performance tool designed for efficient concrete compaction in construction projects. With a powerful 2300 W motor and a 59 mm vibrator head, it delivers excellent consolidation for foundations, walls, and ceilings. The robust design and ergonomic handle ensure comfortable operation, while the reinforced hose and hardened steel head provide durability on demanding job sites.

Advantages

High power output for fast compaction; durable construction with reinforced rubber hose and steel braiding; ergonomic handle with optional shoulder strap for reduced fatigue; overload protection and double insulation for safety; quick-release claw coupling for easy hose attachment.

Suitable for

• Concrete compaction in foundations, walls, and ceilings
• Construction sites requiring reliable and powerful vibration
• Professional contractors and concrete workers

Key specifications

• Power Output: 2300 W
• Operating Voltage: 230 V
• Operating Frequency: 50 Hz
• Vibrator Head Diameter: 59 mm
• Standard Hose Length: 5 m
• Vibration Frequency: 18,000 VPM
• Motor Type: Electric Universal Motor
• Protection Rating: IP44
• Power Cable Length: 1.5 m
• Housing Material: High-impact resistant plastic
• Color Scheme: Black / Blue
• Shaft Coupling Type: Quick-release claw coupling (DIN 48 compatible)
• Max. Amplitude: 1.2 mm
• No-Load Speed: 4000 RPM
• Application: Concrete compaction for foundations, walls, ceilings
• Ergonomics: Ergonomic handle with optional shoulder strap attachment
• Safety Features: Overload protection, double insulation
• Vibrator Head Material: Hardened steel
• Hose Construction: Reinforced rubber with steel braiding
• Recommended Concrete Slump: S1 - S4

Recommendations

For optimal performance, use with a compatible power source and ensure proper hose connection. The GDI59-500 is ideal for medium to large concrete pours where consistent vibration is critical.
