Broadcom Emulex OC10-SR-OPT-1 SFP+ 10GBASE-SR transceiver-module

The Broadcom Emulex OC10-SR-OPT-1 is a high-performance SFP+ transceiver module designed for 10 Gigabit Ethernet networks. It is part of the Emulex OneConnect family, ensuring seamless compatibility with Emulex and Broadcom host bus adapters and network interface cards. This module supports 10GBASE-SR standard over multi-mode fiber, delivering reliable connectivity for data centers and enterprise environments.

Advantages

Hot-swappable design allows for easy installation and replacement without network downtime. Digital Diagnostics Monitoring (DDM) provides real-time monitoring of operating parameters for proactive network management. Low power consumption of less than 1W helps reduce energy costs and heat generation.

Suitable for

• Data center server and storage connectivity
• Enterprise network uplinks and backbone connections
• High-performance computing environments
• Telecommunications and service provider networks

Key specifications

• Form Factor: SFP+
• Data Rate: 10 Gigabit Ethernet (10GbE)
• Interface: 10GBASE-SR
• Wavelength: 850 nm
• Max Distance (OM3 Fiber): 300 meters (984 feet)
• Max Distance (OM4 Fiber): 400 meters (1312 feet)
• Fiber Type: Multi-Mode Fiber (MMF)
• Connector Type: LC Duplex
• Hot-Swappable: Yes
• Digital Diagnostics Monitoring (DDM): Yes
• Power Consumption: < 1W (typically 0.8W)
• Operating Temperature: 0°C to 70°C (Commercial)
• Transmitter Type: VCSEL
• Receiver Type: PIN
• Standards Compliance: IEEE 802.3ae 10GBASE-SR
• Compatibility: MSA Compliant, Emulex/Broadcom Host Bus Adapters and Network Interface Cards

Recommendations

For optimal performance, use with OM3 or OM4 multi-mode fiber and compatible Emulex or Broadcom network adapters. Ensure proper handling and installation to maintain signal integrity.
