Busch-Jaeger audiomodule A251381A-W-03 (2TMA220160W0015)

Connect your smartphone, tablet, or any external audio source to your Busch-AudioWorld® system with this flush-mounted audio module. Ideal for residential and commercial installations, it provides a 3.5 mm stereo jack input for direct playback of your own music through the system speakers.

Key specifications

• Input: 1x 3.5 mm stereo jack (AUX)
• Output: Busch-AudioWorld® system bus
• Power supply: via system bus (24 V DC)
• Current consumption: approx. 20 mA
• Operating temperature: 5 °C to 45 °C
• Storage temperature: -20 °C to 70 °C
• Protection class: IP20
• Material: thermoplastic (PC/ABS)
• Mounting depth: approx. 32 mm
• Installation type: flush-mounted
• Required accessories: central plate and cover frame (sold separately)

Why choose it

This module seamlessly integrates external audio sources into your Busch-AudioWorld® setup, offering stereo sound and reliable performance. Its compact design fits standard flush-mounted boxes, and the bus-powered operation eliminates the need for an additional power supply.

Ideal use cases

• Playing music from a smartphone or tablet in a living room or bedroom
• Connecting a portable media player in a home office
• Integrating a laptop audio output in a conference room

Good to know

The module requires a central plate and cover frame, which are sold separately. It is designed for indoor use only (IP20).
