BUSCH-JAEGER combinatie-wipschakelaar-inzet 2-voudig wisselschakelaar 10A 250V inbouw 2TKA00005545

Controlling two light circuits independently from a single flush-mounted box often requires separate inserts, complicating installation and cluttering the wall. This BUSCH-JAEGER combination rocker switch insert solves that by integrating two two-way switches into one compact unit, enabling independent control of two lighting groups from one location.

Who is it for

Electricians and installers working on residential or commercial projects where a clean, space-saving solution for double switching points is required. It suits renovations and new builds using Busch-Jaeger switch ranges such as Reflex SI or Future Linear.

Main features

• 2-gang (double) insert for controlling two circuits from one flush-mounted box.
• Two-way switching (Wechselschalter) allows each circuit to be operated from two different locations.
• Rated at 250 V AC and 10 A, suitable for standard lighting loads.
• Screw terminals accept conductors up to 2.5 mm², ensuring secure connections.
• Flush-mounted design with thermoplastic mechanism, halogen-free.
• Minimum 40,000 switching cycles for long-term reliability.

Specifications

• Product type: Combination rocker switch insert
• Number of gangs: 2
• Switch function: Two-way switch
• Rated voltage: 250 V AC
• Rated current: 10 A
• Connection type: Screw terminals
• Terminal capacity: Up to 2.5 mm²
• Mounting type: Flush-mounted
• Material: Thermoplastic
• Halogen-free: Yes
• Switching cycles: Min. 40,000
• Compatibility: Busch-Jaeger switch ranges (e.g., Reflex SI, Future Linear)

Tips

Pair with a compatible cover plate and rocker from the same Busch-Jaeger range to complete the installation. Ensure the mounting box depth is sufficient for the insert and wiring.
