Busch-Jaeger studio® centraalplaat 6220-0-0497, studiowit, voor UAE/TAE-aansluitdozen

For electricians and installers setting up UAE/TAE connection boxes in residential or commercial buildings, the Busch-Jaeger studio® central plate 6220-0-0497 provides a clean, snap-in cover in studioweiß (studio white). It fits into standard Busch-Jaeger 1-gang frames and supports two ports, making it suitable for dual-port UAE/TAE inserts.

Key specifications

• Product type: Central plate
• Design line: studio®
• Colour: studioweiß (studio white), RAL 9010
• Material: Thermoplastic (PC), glossy finish
• Mounting: Snap-in into frame
• Number of ports supported: 2
• Halogen-free: Yes
• UV-resistant: Yes
• Protection class: IP20
• Compatibility: Busch-Jaeger standard frames (1-gang)
• Installation area: Indoor
• Operating temperature: -5 to +45 °C

Why choose it

The plate matches the studio® design line for a consistent look and is made of halogen-free, UV-resistant thermoplastic for durability. Its snap-in mounting allows quick installation without tools.

Ideal use cases

• Covering UAE/TAE connection boxes in homes and offices
• New installations or retrofits with Busch-Jaeger frames
• Projects requiring a pure white, glossy finish

Good to know

The plate is designed for indoor use and fits standard 1-gang frames. It does not include the UAE/TAE insert itself.
