Canon flatcable (FK4-5054-000) (FK45054000)

This flexible flat cable (FFC) is the essential internal link between the scanner assembly and main logic board in select Canon PIXMA and imageCLASS devices. Its 30-pin, 0.5 mm pitch design with same-side contacts ensures a compact, reliable connection that withstands the repeated flexing of moving scanner carriages.

Advantages

The blue insulation and bare ZIF/LIF-compatible ends make installation straightforward, while the 450 mm length and 15.5 mm width fit precisely into the designated routing channels. The flat profile reduces electromagnetic interference and saves space compared to round cables, contributing to the printer's overall reliability.

Suitable for

• Canon PIXMA MP250, MP280, MX320, MX340, MX350, MX360, MX410, MX420
• Canon imageCLASS MF4410, MF4430, MF4450, MF4550d, MF4570dn, MF4580dn, MF4710, MF4730, MF4750, MF4770n, MF4780w, MF4820d, MF4830d, MF4870dn, MF4880dw, MF4890dw
• Other Canon devices using a 30-pin 0.5 mm pitch FFC with same-side contacts

Key specifications

• Cable type: Flexible Flat Cable (FFC)
• Conductors: 30-pin, 0.5 mm pitch
• Contact orientation: Type A (same side)
• Length: 450 mm, width: 15.5 mm
• Insulation colour: Blue
• Connector ends: Bare for ZIF/LIF sockets

Recommendations

When replacing this cable, ensure the printer is powered off and disconnected. Handle the FFC by its edges to avoid creasing or damaging the contacts. Align the cable squarely with the connector before locking the ZIF/LIF mechanism.
