DEANTE puntafvoerrooster KOS_001C – RVS 150x150 mm, DN 50/70/100, belastingsklasse K3

With a flow rate of 2.0 l/s at a 20 mm water head (DN100), the DEANTE KOS_001C point drain grate handles high-volume water discharge in showers, wet rooms, and utility areas without pooling. The 150 x 150 mm stainless steel grate sits on a height-adjustable frame, while the removable polypropylene body with integrated 60 mm water trap ensures reliable odour protection and easy cleaning.

Overview

The DEANTE KOS_001C is a complete point drain solution for indoor applications. It combines a polished stainless steel grate with a robust PP drain body and a vertical outlet that accepts DN 50, DN 70, or DN 100 pipes. The flange is designed for composite seals, making it compatible with modern waterproofing systems. Installation is straightforward, with a minimum height of just 110 mm, and the adjustable grate frame allows precise alignment with tile finishes.

What stands out

• Multi-size vertical outlet (DN 50/70/100) for flexible plumbing connections
• Integrated removable water trap with 60 mm seal – prevents sewer odours
• Load class K3 (max. 300 kg) – suitable for residential and light commercial use
• Stainless steel grate 150 x 150 mm – corrosion-resistant and easy to clean
• Height-adjustable frame for perfect alignment with floor level
• Compliant with EN 1253 – meets European drainage standards

Technical details

• Drain type: point drain
• Outlet configuration: vertical
• Outlet diameter: DN 50/70/100 (multi-size)
• Grate material: stainless steel
• Grate dimensions: 150 x 150 mm
• Drain body material: polypropylene (PP)
• Water trap: removable, 60 mm water seal
• Flow rate: 2.0 l/s (with 20mm water head, DN100)
• Load class: K3 (max. 300 kg)
• Minimum installation height: 110 mm
• Application area: indoor, wet rooms, showers, utility rooms
• Sealing type: flange for composite seals
• Odor trap: integrated water trap
• Temperature resistance: up to 95°C
• Grate frame: height adjustable
• Compliance: EN 1253
• Cleaning access: easy, via removable water trap

Our verdict

The DEANTE KOS_001C delivers robust drainage performance in a compact, easy-to-install package. Its multi-size outlet and adjustable frame make it a versatile choice for both new builds and renovations, while the removable trap simplifies maintenance. A reliable, code-compliant solution for any wet area.
