Broadcom 57416 dual-port-10GBASE-T-PCIe-adapter, low profile, klantinbouw

This Dell-branded Broadcom 57416 adapter stands apart from generic NICs by combining dual 10GBASE-T ports with a low-profile form factor and a comprehensive enterprise feature set. It delivers full 10 Gbps throughput over standard Cat6a cabling, eliminating the need for expensive SFP+ modules or fiber. With support for SR-IOV, iSCSI, FCoE, and TCP offload, it is built for virtualized and storage-heavy environments. The card includes both low-profile and full-height brackets, making it a flexible upgrade for a wide range of Dell servers and workstations. Its customer-install design simplifies deployment, while Energy Efficient Ethernet reduces power consumption during idle periods.

Highlights

• Dual RJ-45 ports support 10GBASE-T, 1000BASE-T, and 100BASE-TX for backward compatibility.
• Broadcom BCM57416 controller with PCIe 3.0 x8 interface for high bandwidth and low latency.
• Advanced offloads: TCP/IP Offload Engine (TOE), iSCSI HBA, and FCoE HBA reduce CPU overhead.
• Virtualization-ready with SR-IOV, VMDq, and NetQueue for efficient VM networking.
• Jumbo frame support up to 9 KB improves performance for large data transfers.
• Energy Efficient Ethernet (EEE) and Wake-on-LAN help lower operational costs.
• Includes both low-profile and full-height brackets for versatile installation.

In daily use

In a busy data center or office server, this adapter delivers consistent 10 Gbps connectivity for demanding applications like database replication, backup, and virtualization. The dual ports allow for link aggregation or failover, ensuring high availability. IT administrators will appreciate the PXE boot support for remote deployments and the broad OS compatibility, including Windows Server, Linux, VMware ESXi, and FreeBSD. The card's low-profile design fits into compact 2U or smaller chassis, while the included full-height bracket makes it suitable for tower servers. LED indicators provide quick status checks for link, activity, and speed. With flow control (IEEE 802.3x) and robust driver support, network stability is maintained even under heavy load.

Full specifications

• Brand: Dell
• Model: 540-BBVM?/TD2
• MPN: 540-BBVM?/TD2
• Network Interface: Ethernet Adapter
• Controller Chipset: Broadcom BCM57416
• Number of Ports: 2
• Port Type: RJ-45
• Data Transfer Rate: 10 Gbps
• Network Standards: IEEE 802.3ae, 802.3ab, 802.3u
• Bus Type: PCI Express 3.0 x8
• Form Factor: Low Profile PCIe Card
• Brackets Included: Low-profile and Full-height
• Jumbo Frame Support: Up to 9 KB
• Virtualization Support: SR-IOV, VMDq, NetQueue
• PXE Support: Yes
• OS Compatibility: Windows Server, Linux, VMware ESXi, FreeBSD
• Advanced Features: TOE, iSCSI HBA, FCoE HBA, EEE
• LED Indicators: Link/Activity, Speed
• Cabling: Cat6a or higher for 10GBASE-T
• Wake-on-LAN: Yes
• Flow Control: IEEE 802.3x

Final note

For enterprises needing reliable, high-speed copper networking with advanced virtualization and storage features, the Broadcom 57416 adapter is a proven choice. Its low-profile design and included brackets ensure compatibility with virtually any Dell system, making it a straightforward upgrade path to 10 Gigabit Ethernet.
