DELOCK CAN 2.0 / CAN FD PCIe-interfacekaart, 2 x D-Sub 9 pin, tot 8 Mbps, met isolatie en overspanningsbeveiliging

Unlike basic USB-to-CAN adapters, this DELOCK PCIe card delivers dual isolated CAN 2.0 / CAN FD channels directly to your desktop or server, ensuring low latency, deterministic timing, and a permanent internal installation for industrial automation, automotive diagnostics, and embedded development. The PCIe x1 form factor provides a stable, high-performance connection that outperforms external dongles in demanding environments.

Highlights

• Dual-channel CAN 2.0 A/B and CAN FD interface via PCIe x1
• Two D-Sub 9-pin connectors, each with 1 kV galvanic isolation and surge protection
• Supports bit rates from 10 kbps up to 8 Mbps (CAN FD data phase)
• Compatible with Windows and Linux operating systems
• Low-profile bracket included for slimline systems

In daily use

The card integrates seamlessly into existing CAN networks, whether you are monitoring vehicle buses, controlling industrial machinery, or developing CAN FD nodes. The isolation protects your PC from ground loops and voltage spikes, while the surge protection guards against transients commonly found in automotive and industrial environments. Drivers and utilities are available from the manufacturer, enabling straightforward configuration of bit timing, acceptance filters, and message logging.

Full specifications

• Interface: PCIe x1, version 2.0
• CAN controller: dual independent channels
• CAN standards: CAN 2.0 A/B, CAN FD (ISO 11898-1:2015)
• Data rates: 10 kbps – 1 Mbps (CAN 2.0), up to 8 Mbps (CAN FD)
• Connectors: 2 x D-Sub 9-pin male
• Isolation: 1 kV DC per channel
• Surge protection: on each port
• Operating temperature: 0 °C to 55 °C
• Storage temperature: -20 °C to 70 °C
• Operating relative humidity: 10% to 90% non-condensing
• Power consumption: 2.5 W typical
• Dimensions: 120 mm x 80 mm x 20 mm
• Weight: 120 g

Final note

For reliable, isolated CAN connectivity in a fixed installation, this DELOCK card offers the performance and protection your industrial or automotive projects demand.
