DELOCK inbouwadapter IEC C14 stekker naar F-bus, zwart 91204

In broadcast facilities and RF test benches, technicians often need to route both mains power and coaxial signals through a single chassis plate. The DELOCK 91204 solves this neatly: a panel-mountable adapter that combines an IEC C14 inlet with a 75-ohm F-type jack, all in a compact black plastic housing.

Key specifications

• Connector 1: IEC C14 plug (male), 3-pin, rated 10 A / 250 V
• Connector 2: F-type jack (female), 75 Ohm impedance
• Frequency range: 0 – 2.4 GHz
• Mounting: panel mount with screw holes (diameter 3.5 mm, distance 36.0 mm)
• Panel cutout: 28.0 x 20.0 mm
• Housing material: plastic, black
• Operating temperature: -20 °C to 80 °C

Why choose it

This adapter saves space and simplifies wiring by integrating power and RF connections in one unit. The F-type jack maintains a stable 75-ohm impedance for clear signal transmission, while the IEC C14 plug provides a reliable power inlet. Its plastic housing is lightweight yet durable, and the standard cutout dimensions allow easy retrofitting into existing panels.

Ideal use cases

• Broadcast equipment racks requiring combined power and RF feedthrough
• Test and measurement setups where coaxial signals and mains power share a panel
• Custom enclosures for media converters, modulators, or RF distribution units
• Industrial control panels needing a compact power/signal interface

Good to know

The adapter is designed for panel thicknesses up to 3 mm. It includes mounting screws and nuts for secure installation. The F-type jack is compatible with standard 75-ohm coaxial cables using F connectors. Ensure proper grounding and insulation when handling mains voltage.
