DINITECH diamantschijf EDGE DRY 115 x 1,6 x 25 x 22,23 mm

The DINITECH Diamond Blade EDGE DRY is a high-performance cutting tool designed for dry cutting of hard materials. With a diameter of 115 mm and a continuous diamond rim, it delivers fast and clean cuts in porcelain stoneware, ceramics, granite, marble, and hard tiles. Ideal for use with angle grinders, this blade offers high wear resistance and durability.

Advantages

Fast and clean cutting performance; dry cutting capability eliminates need for water cooling; high wear resistance ensures long service life; sintered bond provides consistent cutting quality; compatible with standard angle grinders.

Suitable for

• Porcelain stoneware
• Ceramics
• Granite
• Marble
• Hard tiles

Key specifications

• Blade Diameter: 115 mm
• Bore Diameter: 22.23 mm (7/8 inch)
• Segment Thickness: 1.6 mm
• Segment Height: 25 mm
• Maximum RPM: 13300 RPM
• Cutting Method: Dry
• Blade Design: Continuous Diamond Rim
• Bond Type: Sintered
• Blade Body Material: High-grade Steel

Recommendations

For optimal performance, use with a variable speed angle grinder set to the appropriate RPM. Always wear appropriate safety gear including eye protection and gloves. Ensure the blade is properly mounted and tightened before use.
