Eaton DILM400-XHB hulpcontactblok, 2NO+2NC, frontmontage, schroefklemmen 208287

Auxiliary contact block for Eaton DILM series contactors, providing four additional switching contacts with a 2 normally open and 2 normally closed configuration. It mounts directly onto the front of compatible contactors, expanding control and signaling capabilities in industrial control circuits.

Advantages

The front mounting design allows quick installation without tools, while screw terminals ensure secure and reliable wiring. The contact block is rated for 6 A at AC-15 (230 V) and 0.3 A at DC-13 (220 V), making it suitable for a wide range of auxiliary control applications.

Suitable for

• Eaton DILM400 contactors
• Eaton DILM500 contactors
• Eaton DILM650 contactors
• Eaton DILM820 contactors

Key specifications

• Contact configuration: 2 NO + 2 NC
• Rated operational current (AC-15, 230 V): 6 A
• Rated operational current (DC-13, 220 V): 0.3 A
• Rated insulation voltage (Ui): 690 V
• Rated impulse withstand voltage (Uimp): 6 kV
• Terminal type: screw terminals
• Degree of protection: IP20 (terminals)
• Operating temperature range: -25 to +60 °C
• Connection capacity (solid): 1 x (0.75 - 2.5) mm², 2 x (0.75 - 2.5) mm²
• Connection capacity (stranded with ferrule): 1 x (0.75 - 2.5) mm², 2 x (0.75 - 2.5) mm²
• Number of poles: 4

Recommendations

Verify compatibility with your specific contactor model before installation. Ensure all connections are properly tightened to the specified torque to maintain reliable operation.
