Eaton EVG-3PHAS/N/5MODUL/LS voorbedrade verdeelgroep, 3-fasen + nul, 5 modules, rood 215659

This Eaton pre-wired distribution group consolidates a 4-pole residual current device and four miniature circuit breakers into a single 5-module unit, simplifying three-phase distribution board assembly. The red housing distinguishes it from standard grey components, making it easy to identify in mixed installations.

Highlights

• Integrated 4-pole RCD (40 A, 30 mA, Type A) with three 1-pole 16 A B-curve MCBs and one 3-pole 16 A B-curve MCB
• Pre-wired for 3-phase + neutral systems, reducing wiring time and errors
• Compact 5-module width fits standard DIN rail distribution boards
• Rated voltage 230/400 V AC, 50/60 Hz, suitable for residential and light commercial use

In daily use

Installers benefit from the factory-wired connections, which eliminate the need to link individual devices. The unit mounts on a 35 mm DIN rail (EN 60715) and provides screw terminals for secure conductor termination. The combination of RCD and MCBs offers both residual current protection and overcurrent protection for final circuits.

Full specifications

• Product type: Pre-wired distribution group
• System configuration: 3-phase + neutral
• Module width: 5 DIN modules
• Main protective device: Residual current device (RCD), 4-pole, 40 A, 30 mA, Type A
• Included MCBs: 3x 1-pole 16 A B-curve, 1x 3-pole 16 A B-curve
• Rated operating voltage: 230/400 V AC
• Rated frequency: 50/60 Hz
• Mounting type: DIN rail (EN 60715)
• Short-circuit breaking capacity (MCBs): 6 kA
• Degree of protection (components): IP20
• Terminal type: Screw terminals
• Housing material (components): Thermoplastic

Final note

Pre-wired distribution groups like this Eaton unit streamline panel building, ensuring consistent protection and reducing installation labour.
