Eaton Y7-170431 FRCMM-25/2/003-A aardlekschakelaar, 2-polig, 25 A, 30 mA, type A

Electrical faults can cause dangerous leakage currents that standard circuit breakers do not detect, putting people and equipment at risk. The Eaton Y7-170431 FRCMM-25/2/003-A residual current circuit breaker (RCCB) provides essential protection by instantly disconnecting the circuit when a residual current of 30 mA or more is detected.

Who is it for

This RCCB is intended for electricians and panel builders installing protection in residential, commercial, and light industrial electrical distribution boards. It is suitable for circuits where protection against both AC and pulsating DC residual currents is required.

Main features

• 2-pole design for single-phase 230 V AC circuits
• Rated current 25 A, suitable for a wide range of loads
• Sensitivity 30 mA (0.03 A) for personal protection against electric shock
• Type A tripping: detects AC and pulsating DC residual currents
• Compact 2-module width (35 mm) for DIN rail mounting
• High short-circuit withstand rating of 10 kA

Specifications

• Device type: Residual Current Circuit Breaker (RCCB)
• Number of poles: 2
• Rated current (In): 25 A
• Rated residual operating current (IΔn): 30 mA
• RCD type: A
• Rated voltage: 230 V AC
• Rated frequency: 50/60 Hz
• Rated short-circuit breaking capacity: 10 kA
• Rated impulse withstand voltage: 4 kV
• Mounting type: DIN rail
• Module width: 2 modules
• Degree of protection: IP20 (terminals), IP40 (with enclosure)
• Operating temperature: -25 to +40 °C
• Terminal capacity: 1–25 mm² solid, 1–16 mm² flexible
• Mechanical endurance: 20,000 operations
• Electrical endurance: 10,000 operations
• Standards: EN 61008

Tips

Always verify that the RCCB's rated current and sensitivity match the circuit requirements and local regulations. Test the device regularly using the test button to ensure proper operation.
