Elsys Eco Series CO2 Lite - temperatuur- en luchtvochtigheidssensor

The Elsys Eco Series CO2 Lite is a professional-grade LoRaWAN sensor designed for accurate monitoring of CO2 levels, temperature, and humidity in indoor environments. Ideal for smart building automation, HVAC optimization, and indoor air quality management, this sensor provides reliable data with long battery life and easy configuration via NFC or downlink.

Advantages

High accuracy CO2, temperature, and humidity sensing; long battery life up to 10 years; easy configuration via NFC or LoRaWAN downlink; supports multiple frequency bands for global deployment; compact and robust design for wall mounting.

Suitable for

• Indoor air quality monitoring in offices, schools, hospitals, and homes
• HVAC control and energy efficiency optimization
• Smart building and IoT applications

Key specifications

• Sensor Types: CO2, Temperature, Humidity
• Connectivity: LoRaWAN (Class A, Protocol 1.0.3)
• CO2 Range: 400-5000 ppm, Accuracy: ±30 ppm + 3% of reading
• Temperature Range: 0-40°C, Accuracy: ±0.5°C
• Humidity Range: 0-85%RH, Accuracy: ±2%RH
• Power: 2x AA batteries (3.6V Lithium recommended)
• Battery Life: Up to 10 years
• Configuration: NFC, LoRaWAN Downlink
• Mounting: Wall mount
• Enclosure: ABS Plastic
• Certifications: CE, FCC, IC, RCM, LoRaWAN Certified

Recommendations

For optimal performance, use 3.6V Lithium AA batteries and configure the sensor via the Elsys NFC app. Ensure the sensor is placed in a well-ventilated area away from direct sunlight or heat sources.
