Equip 16-poorts Cat.5e afgeschermd patchpaneel, lichtgrijs

The equip® Patch Panel is a 19" 1U network distribution unit with integrated cable management, designed for organized rack-mounted network installations. It provides 16 shielded RJ45 ports compatible with Cat5e shielded cabling and supports both LSA and 110 termination standards. Each port is numbered for easy identification and the panel is intended to be used with equip® shielded patch cords and cabling accessories to ensure consistent performance.

Advantages

The patch panel offers a compact 1U form factor for standard 19" racks, shielded RJ45 connections with gold-plated contacts for reliable signal transmission, and built-in cable management and strain relief to simplify routing and maintain cable integrity. Clear port numbering improves installation and maintenance efficiency.

Suitable for

• Small and medium business network racks
• Structured Cat5e shielded cabling installations
• Server rooms and communication cabinets requiring 1U rack space
• Environments using LSA or 110 punch-down termination

Key specifications

• Brand: EQUIP
• Model / MPN: 327316
• EAN: 4015867523483
• Ports: 16 × shielded RJ45
• Cabling standard: Cat5e (shielded)
• Termination: LSA and 110 compatible
• Rack size: 19" 1U
• Dimensions (H×W×D): 44 mm × 483 mm × 109 mm
• Colour: Light grey
• Contact plating: Gold

How to use

Mount the patch panel into a standard 19" rack occupying 1U of space. Terminate shielded Cat5e cables to the rear LSA or 110 punch-down blocks according to the cable colouring and the chosen wiring scheme. Connect shielded RJ45 patch cords to the front ports and ensure the cable shield is properly grounded via the panel or rack grounding point. Use the integrated cable management and strain relief to route and secure incoming and outgoing cables to prevent excess bending and mechanical stress.

Recommendations

For best results, use equip® shielded patch cords and maintain proper grounding of the shielded cabling. Label cables and record port mappings during installation to simplify future maintenance and troubleshooting.
