ETI EPC-VDS Mini-ventilatoreenheid voor EPC-serie behuizing, 230V AC, 23 m³/h, IP54 001102634

With an airflow of 23 m³/h at 50 Hz, the ETI EPC-VDS mini fan unit provides efficient ventilation for EPC series enclosures, ensuring reliable heat dissipation and protection for sensitive components.

Overview

The ETI EPC-VDS is a compact axial fan unit designed for snap-in mounting into ETI EPC series enclosures. It operates on 230V AC and includes a filter mat for IP54 protection, making it suitable for industrial environments where dust and moisture resistance is required.

What stands out

• Snap-in mounting for quick installation without tools.
• Integrated filter mat provides IP54 protection.
• Low noise level of 32 dB at 50 Hz for quiet operation.
• Wide operating temperature range from -10°C to +55°C.

Technical details

• Power supply: 230V AC, 50/60 Hz
• Airflow: 23 m³/h (50 Hz), 26 m³/h (60 Hz)
• Power consumption: 14 W (50 Hz), 12 W (60 Hz)
• Noise level: 32 dB (50 Hz), 35 dB (60 Hz)
• Protection rating: IP54 with filter mat
• Operating temperature: -10°C to +55°C
• Mounting: Snap-in
• Frame material: ABS plastic
• Fan impeller material: Metal
• Cut-out dimensions: 92 x 92 mm
• Filter included: Yes (filter mat)
• Fan type: Axial
• Connection: Terminal block
• Compatibility: ETI EPC series enclosures

Our verdict

The ETI EPC-VDS is a reliable and easy-to-install ventilation solution for EPC enclosures, offering balanced airflow, low noise, and IP54 protection for demanding industrial applications.
