EXERTIS CONNECT OM2 LWL-patchkabel, 50/125 µm, SC Duplex naar LC Duplex, UPC, oranje, 10 m 392686

Low attenuation of < 2.5 dB/km at 850 nm keeps signal loss minimal. This 10 m OM2 multimode fibre patch cable connects SC Duplex to LC Duplex with UPC polished connectors, ideal for reliable indoor network links.

Overview

The EXERTIS CONNECT Eco fibre patch cable is built with 50/125 µm OM2 multimode fibre, offering a cost-effective solution for short-range data transmission. The orange PVC jacket provides durability and easy identification in structured cabling environments.

What stands out

• Duplex configuration supports bidirectional communication over two fibres.
• UPC polish on both connectors ensures low back reflection and stable performance.
• Flexible design with a minimum bend radius of 30 mm for easy routing.

Technical details

• Fibre type: OM2 multimode, 50/125 µm
• Connectors: SC Duplex to LC Duplex, UPC polish
• Length: 10 m
• Jacket: PVC, orange
• Attenuation: < 2.5 dB/km at 850 nm, < 0.8 dB/km at 1300 nm
• Operating temperature: -20°C to 70°C

Our verdict

A dependable OM2 patch cable for indoor fibre connections, combining standard connectors with solid performance at a budget-friendly price.
