EXSYS EX-3660 M.2 naar SATA III adapterkaart - B-Key/B+M Key, 6 Gbps, ondersteunt 2230/2242/2260/2280

Connect a standard SATA III device to an M.2 SATA slot with the EXSYS EX-3660. This adapter delivers up to 6 Gbps data transfer, the maximum of the SATA III interface, ensuring your storage runs at full speed.

Overview

The EX-3660 is a compact M.2 to SATA adapter card. It plugs into an M.2 B-Key or B+M Key slot that carries SATA signals, and provides one 7-pin SATA III port for connecting a hard drive or SSD. The adapter supports M.2 modules in 2230, 2242, 2260, and 2280 form factors.

What stands out

• Full 6 Gbps SATA III speed
• Supports four common M.2 lengths
• Bus-powered, no extra power cable needed
• Hot-swap capability for connected SATA devices
• OS independent, no drivers required

Technical details

• Host interface: M.2 B-Key / B+M Key (SATA-based)
• Device interface: 1x SATA III 7-pin
• Data transfer rate: up to 6 Gbps
• Supported M.2 sizes: 2230, 2242, 2260, 2280
• Power: via M.2 bus
• Material: PCB

Our verdict

An efficient way to add a SATA port to systems with an M.2 SATA slot, especially in compact builds.
