Finder 62.83.8.230.4009 vermogensrelais 3 CO 16A 230V AC Faston 250

Power relay with 3 changeover contacts (3PDT) for switching loads up to 16 A. The 230 V AC coil and Faston 250 terminals make it suitable for direct panel mounting in industrial control systems.

Advantages

Silver nickel contacts ensure reliable switching of high inrush currents. Flux-proof construction protects against dust and solder flux during assembly.

Suitable for

• Industrial automation and control panels
• Heating, ventilation and air conditioning systems
• Motor control circuits
• Power distribution and switching applications

Key specifications

• Contact configuration: 3 CO (3PDT)
• Rated current: 16 A
• Coil voltage: 230 V AC
• Contact material: AgNi
• Terminal type: Faston 250 (6.3 x 0.8 mm)
• Dielectric strength coil-contact: 2500 V AC
• Dielectric strength open contacts: 1000 V AC
• Max switching voltage: 400 V AC
• Max switching power (AC1): 4000 VA
• Coil power: 2.8 VA
• Operating temperature: -40 to +70 °C
• Mechanical life: 10 x 10^6 operations
• Electrical life at rated load: 100 x 10^3 operations
• Protection degree: RT I (flux proof)
• Mounting type: plug-in / panel mount

Recommendations

Use with socket for easy replacement and maintenance. Ensure coil voltage matches control circuit.
