FRITZ!Box 7632 Wi-Fi 7 DSL/G.fast-router, dual-band

The FRITZ!Box 7632 is a Wi-Fi 7 DSL/G.fast router with dual-band Wi-Fi and integrated modem for all DSL connections. It supports G.fast up to 1000 Mbit/s and VDSL up to 300 Mbit/s, and includes a telephone system with DECT base for up to 6 cordless phones.

Key features

• Wi-Fi 7 (802.11be) dual-band (2.4 GHz/5 GHz) with up to 3568 Mbit/s
• Integrated modem for all DSL connections, G.fast up to 1000 Mbit/s, VDSL up to 300 Mbit/s
• 1 x 2.5-Gigabit WAN/LAN, 3 x Gigabit LAN
• Telephone system for IP-based connections, integrated DECT base for up to 6 cordless phones
• 5 integrated answering machines incl. Voice to Mail, fax function incl. Fax to Mail
• Smart Home functions for electricity, heating and light
• 1 x USB 3.0 for printer and storage in the network
• FRITZ!NAS – shared storage for all data in the home network
• WLAN Mesh, WPA3/WPA2 encryption, WPS

Specifications

• Brand: Fritz!
• MPN: 20003167
• Product colour: White
• Product type: Tabletop router
• Wi-Fi: Yes
• Wi-Fi standards: Wi-Fi 7 (802.11be), Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11a, 802.11g
• WLAN band: Dual-band (2.4 GHz/5 GHz)
• WLAN data transfer rate (max.): 3568 Mbit/s
• WLAN data transfer rate (first band): 688 Mbit/s
• WLAN data transfer rate (second band): 2880 Mbit/s
• Number of channels: 4
• Ethernet LAN: Yes
• Ethernet LAN interface type: Gigabit Ethernet
• Number of Ethernet LAN ports (RJ-45): 4
• LAN speeds: 100 Mbit/s, 1000 Mbit/s, 2500 Mbit/s
• Ports: 4x RJ-45 (LAN), 1x RJ-11 (analog), 1x USB-A 3.2 (5 Gbit/s)
• USB: Yes
• WAN connection: Ethernet-WAN, DSL-WAN
• DSL features: ADSL, ADSL2+
• Mobile network generation: 5G
• Supported security algorithms: WPA3, WPA2
• Security features: Firewall, Guest access, Stateful Packet Inspection (SPI), Parental control
• Management features: Web-based management, WPS (Wi-Fi Protected Setup)
• MIMO: Yes
• Media server: Yes
• VPN passthrough: Yes
• LED indicators: Power, WPS, WLAN
• Antenna design: Internal
• Wall mounting: Yes
• Supported languages: German
• Upgradable firmware: Yes
• Power source: AC
• AC input voltage: 220 V
• Width: 254 mm
• Depth: 191 mm
• Height: 63 mm
• Weight: 525 g
