GEDORE red ring-ratel-combinatiesleutel, 22 mm, 285 mm lengte R07100220

Professional mechanics and maintenance technicians rely on this GEDORE red ring ratchet combination wrench for fast, efficient tightening and loosening of 22 mm fasteners. The fine-toothed ratchet mechanism with 72 teeth provides a 5° return angle, allowing work in tight spaces where swing room is limited. The open end features a hexagonal profile for high torque transmission, while the ring end uses a 12-point (bi-hex) profile to grip fasteners securely. Made from chrome vanadium steel with a matt chrome-plated finish, the wrench is hardened and tempered for durability and corrosion resistance. The 15° offset on the ring end improves knuckle clearance and access to recessed fasteners.

Key specifications

• Wrench type: Ring ratchet combination wrench
• Size (spanner width): 22 mm
• Length: 285 mm
• Material: Chrome vanadium steel
• Surface finish: Matt chrome-plated
• Ratchet mechanism: Fine-toothed, 72 teeth
• Return angle: 5°
• Head offset (ring side): 15°
• Drive profile (open end): Hexagonal
• Drive profile (ring end): 12-point (bi-hex)
• Standards met: DIN 3113, ISO 3318
• Handle type: Straight shaft

Why choose it

The combination of a ratcheting ring end and a fixed open end offers versatility for both speed and high-torque applications. The fine-toothed ratchet allows precise engagement even in confined areas, reducing the need to reposition the wrench frequently. Chrome vanadium steel ensures long service life under demanding workshop conditions.

Ideal use cases

• Automotive repair and maintenance
• Industrial machinery assembly
• Agricultural equipment servicing
• General mechanical work where 22 mm fasteners are common

Good to know

The wrench meets DIN 3113 and ISO 3318 standards, ensuring dimensional accuracy and performance. The matt chrome-plated finish provides a non-glare surface and protects against corrosion. The straight shaft design offers a comfortable grip and balanced feel during use.
